MCX 1 Cartridge

MCX 1 Cartridge

$795.00
          (0 reviews)
Out of stock
+
  Add to Wishlist
The Acoustic Signature MCX 2 is a modern moving-coil cartridge, manufactured according to the latest technologies. Free Shipping to Continental US Only! Questions? Please call us at (702) 910-4913. Or contact us via Chat.

The optimal partner for our NEO tonearm series. An elliptical stylus assuring precise tracking results, copper coils and a CNC-milled and resonance-optimized chassis developed according to the finite element design principle form the basis for a true all-rounder.

Features

- Modern MC cartridge with copper coils

- Resonance-optimized aluminum chassis

- Easy mounting

- Precise tracking due to elliptical stylus

- Suitable for medium to high mass tonearms

Specifications

Voltage Output at 1k Hz, 5 cm / sec.:  0.55 mV

Channel Balance at 1k Hz : < 1.5 dB

Channel Separation at 1k Hz : > 21 dB

Compliance : 15 µm / mN

Tracking Force Range : 2.1 - 2.5 grams

Recommended Tracking Force : 2.3 grams ( 23 mN )

Frequency Range at -3dB : 20 - 25k Hz

Frequency Response 20 - 20k Hz : ± 2.5 dB

DC Resistance : 7 Ohm

Coil Material : Copper

Cartidge Weight : 12.2 grams

Recommended Load : 100 Ohm
