Features

- 2.1MP High Definition

- Smart Tracking

- 1920X1080P@30fps

- 4.7-94mm Lens

- 20x Optical Zoom

- 1/2.8” CMOS

- 10 IR LEDs@495ft

- Alarm In / Out

- AC 24V, High PoE

- 6"(Φ)

- Wall Mount Bracket Included

Specifications

Camera

Image Sensor: 1/2.8’’ sensor
Effective Pixel: 2230K pixels
Min. Illumination Color: [email protected], AGC ON;
B/W: [email protected], AGC ON)
White Balance: Auto / Manual /ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp
AGC: Auto / Manual
S / N Ratio: ≥ 52dB
Digital Noise Reduction: 3D DNR
Backlight compensation: BLC
Wide Dynamic Range: 128X Digital WDR
Shutter Speed: 1 ~ 1/10,000s
Day & Night: IR Cut Filter
Focus Mode: Auto / Semiautomatic / Manual

Lens

Focal Length: 4.3 ~ 129mm, 30x
Zoom Speed: Approx 3s(Optical Wide-Tele)
Angle of View: 65.1 ~2.34 degree (Wide-Tele)
Min. Working Distance: 10 ~ 1500mm(Wide-Tele)
Aperture Range: F1.6 ~F5.0

Pan and Tilt

Pan / Tilt Range Pan: 360° endless; Tilt: -5° ~ 90° (Auto Flip )
Pan / Tilt Speed Pan Manual Speed: 0.1° ~ 250°/s, Pan Preset Speed: 300°/s
Tilt Manual Speed: 0.1° ~ 150°/s, Tilt Preset Speed: 200°/s
Proportional Zoom: Rotation speed can be adjusted automatically according to zoom multiples
Number of Preset: 256
Park Action: Pattern/Pan scan/Tilt scan/Frame scan/Panorama scan/Random scan
Patrol: 8 patrols, up to 32 presets per patrol
Power-off Memory: Support

Input/ Output

Audio Input: Audio input (Line input), 2 ~ 2.4V[p-p]; output impedance: 1KΩ±10%
Audio Output: Line level, impedance: 600Ω

Network

Ethernet: 10Base-T / 100Base-TX, RJ45 connector
Max. Image Resolution: 1920×1080
Frame Rate: 60Hz 30 fps (1920×1080),30 fps (1280×960) , 30 fps (1280×720)
50Hz: 25 fps (1920×1080),25 fps (1280×960) , 25 fps (1280×720)
Image Compression: H.264/MPEG4
Audio Compression: G.711u /G.711a /G.726
Protocols: IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE
Simultaneous Live View: Up to 6
Streams: Dual Streams
Mini SD Memory Card: Micro SD Slot, up to 32GB
User/Host Level: Up to 32 users, 3 Levels: Administrator, Camera control, Live view only
Security Measures: User authentication (ID and PW), Host authentication (MAC address), IP address filtering

Integration

Application Programming: Open-ended API, support Onvif, PSIA and CGI
Web Browser: IE 7, IE 8, IE 9, Chrome 8 +, Firefox 3.5 +, Safari 5 +

General

Working Temperature/Humidity: -22°F ~ 149°F  90% or less
Power Supply: 24 VAC / PoE+;
Power Consumption: Max. 22W
Ingress Protection Level: IP66 standard
TVS 4,000V lightning protection, surge protection and voltage transient protection
Impact Protection: IEC60068-275Eh, 20J; EN50102, up to IK10
Dimensions: 8.66” × 12.02” without bracket
Weight: 11.02 lbs without bracket
