In addition to CD it has 3 digital inputs: coax, optical and asynchronous USB. This makes it particularly useful for set top boxes and/or TV sound improvement. The technical performance is excellent; it has very low distortion, extremely low jitter, excellent signal-to-noise ratio, extremely flat frequency response, exemplary linearity and excellent channel separation.
All in all the M3SCD gives excellent CD replay and can act as a versatile digital hub at the same time.
M3SCD In Brief
- CD Player & Digital Hub
- Excellent technical performance
- Very good CD readability
- Multiple digital inputs - coax, optical and asynchronous USB
- Very low jitter
- Excellent build quality and convenient size
Jitter: <135 picoseconds peak to peak
Frequency Response: 10Hz to 20 kHz -0.2dB max.
Signal to Noise Ratio: >117dB
THD ( + noise ): <0.003% 10Hz to 20 kHz
Linearity: <0.1dB down to -96dB
Channel Separation: 105dB 20 Hz to 20 kHz
DAC:24 bit Delta-Sigma ( bit stream ) dual differential 8x over-sampling
1 x line level RCA
1 x RCA Coaxial Connector ( Digital SPDIF )
1 x Toslink Optical Connector ( Digital SPDIF )
1 x Trigger output - 3.5 mm ( 1/8” ) mono jack +12V DC
1 x RCA coaxial connector SPDIF 32-192 kbps ( 16-24 bit Stereo PCM )
1 x TOSLINK optical connector 32-96 kbps ( 16-24 bit Stereo PCM )
1 x USB type ‘B’ connector -
Asynchronous data stream at up to 24-bit/96kHz
Dimensions: 440 ( W ) x 100 mm ( H ) x 380 mm ( D )
Net Weight 6.05 kg
Shipping Weight & Dimensions: 9.9 kg, 22 lbs , 21.5" x 19.5" x 10"
