Product description

    In addition to CD it has 3 digital inputs: coax, optical and asynchronous USB. This makes it particularly useful for set top boxes and/or TV sound improvement. The technical performance is excellent; it has very low distortion, extremely low jitter, excellent signal-to-noise ratio, extremely flat frequency response, exemplary linearity and excellent channel separation.

    All in all the M3SCD gives excellent CD replay and can act as a versatile digital hub at the same time.

    M3SCD In Brief

    - CD Player & Digital Hub

    - Excellent technical performance

    - Very good CD readability

    - Multiple digital inputs - coax, optical and asynchronous USB

    - Very low jitter

    - Excellent build quality and convenient size

    Musical Fidelity M3SCD CD Player User's Manual

    Performance

    Jitter: <135 picoseconds peak to peak

    Frequency Response: 10Hz to 20 kHz -0.2dB max.

    Signal to Noise Ratio: >117dB

    THD ( + noise ): <0.003% 10Hz to 20 kHz

    Linearity: <0.1dB down to -96dB

    Channel Separation: 105dB 20 Hz to 20 kHz

    Hardware

    DAC:24 bit Delta-Sigma ( bit stream ) dual differential 8x over-sampling

    Outputs

    1 x line level RCA

    1 x RCA Coaxial Connector ( Digital SPDIF )

    1 x Toslink Optical Connector ( Digital SPDIF )

    1 x Trigger output - 3.5 mm ( 1/8” ) mono jack +12V DC

    Inputs

    1 x RCA coaxial connector SPDIF 32-192 kbps ( 16-24 bit Stereo PCM )

    1 x TOSLINK optical connector 32-96 kbps ( 16-24 bit Stereo PCM )

    1 x USB type ‘B’ connector -

    Asynchronous data stream at up to 24-bit/96kHz

    Trigger in

    General

    Dimensions: 440 ( W ) x 100 mm ( H ) x 380 mm ( D )

    Net Weight 6.05 kg

    Shipping Weight & Dimensions: 9.9 kg, 22 lbs , 21.5" x 19.5" x 10"
