Focal Series 100 OD8 Outdoor Loudspeaker (Each)

The Loudspeaker that Stands up to All Weathers!

In addition to its UV-treated, high-density Polypropylene damping cabinet, the 100 OD8* loudspeaker is IP66 certified** (Ingress Protection rating 66). This reference international standard demonstrates the remarkable resistance of products to extreme weather conditions, and more specifically their watertight and dust-proof qualities. Integrating Focal Technologies, the 100 OD8 loudspeaker delivers the Focal’s high-fidelity sound outdoors. It is also easy to install, thanks to its reinforced, notched assembly bracket. Its 180-degree rotation system makes it easy to position, too. And because, at Focal, attention is paid to each and every detail and to satisfying every taste, the grille and cabinet are available in black finish or white ready-to-paint finish.

Focal Technologies

An aluminum inverted dome tweeter for excellent sound dispersion; bass/mid-range speaker driver with a waterproof Polypropylene cone and Polyglass treatment for perfect definition: the 100 OD8 loudspeaker features high-performing "made in Focal" components that all have a part to play in the sharing and experience of the Focal sound. 100 OD8 delivers a slightly higher efficiency and a power handling to 100 OD6, allowing configurations with higher volume.

Complementarity

With its high impedance (8 ohms), the 100 OD8 loudspeaker offers the possibility of connecting two loudspeakers in parallel on the same amplifier output.

Easy to Install & Use

100 OD8 is equipped with a reinforced, notched assembly bracket made from solid, anti-rust Aluminium, and offers the option to rotate the loudspeaker 180 degrees for unbeatable sound diffusion. The product is therefore easier to install, as well as to position, either vertically or horizontally, depending on your preference and the layout of your outdoor space.

Key Points

- Technical design, IP66 certified (water and dust)

- Ready-to-paint grille and cabinet

- 8 ohms impedance, possibility to connect 2 loudspeakers to the same amplifier output

Specifications

Type: Outdoor loudspeaker

Speakers:

Aluminum inverted dome tweeter

8" (210mm) waterproof woofer with Polyglass treatment

Sensitivity: 88dB

Frequency Response: 60Hz-23kHz

Low Frequency Point: (-6dB) 45Hz

Nominal Impedance: 8Ώ

Minimal Impedance: 6.7Ώ

Recommended Amp Power: 20-150W

Filtering Frequencies: 2,800Hz

Dimensions: ( with brackets ) 10.2" ( L ) x 11" ( P ) x 15.4" ( H )

Net Weight: ( with brackets ) 12.6 lbs

Focal 100 OD8 Quick Start Guide

Focal 100 OD8 User's Manual

Focal 100 OD8 Specification Sheet
