NDX 2 Network Music Player

NDX 2 Network Music Player

$8,799.00
          (0 reviews)
Call us for shipping information
+
  Add to Wishlist
The NDX 2 features an integrated low-noise power supply with a custom-designed toroidal transformer & separate windings for the digital and analogue sections. Free shipping to Continental US only!

With its world-class performance, the versatile and upgradable NDX 2 embodies the current state of the art. A host of features such as high-res UPnPTM streaming, AirPlay, AirPlay 2, Chromecast built-in, Bluetooth ( aptX HD ), Spotify Connect, TIDAL, Qobuz, Roon compatibility, vTuner internet radio and multi-room streaming as well as digital and USB inputs provide all the connectivity you could wish for.

Our main focus in developing the NDX 2 network player, however, was its performance. Along with Naim’s bespoke streaming platform, we implemented an upgraded DAC and discrete analogue stages. These and numerous other improvements over its acclaimed predecessor make the NDX 2 a sonic force to be reckoned with, offering highly immersive and lively replay quality.

Features

- UPnP-enabled to allow streaming of audio files at up to 32bit/384kHz resolution from Naim Audio hard disk servers, network-attached storage ( NAS ) devices or any home computer

- Supports a broad range of music formats: WAV, FLAC, DSD, Apple Lossless, AIFF, AAC, Windows Media-formatted files, M4A and MP3. Gapless playback on all file formats

- Four 24bit/192kHz capable digital inputs ( S/PDIF ) to support optimum connection to external sources

- 5” colour display presenting album artwork as well as track information

- Built-in Chromecast allows you to stream from hundreds of supported smartphone or tablet apps ( 192kHz )

- Apple AirPlay - stream music from your iOS device or from iTunes and Apple Music

- Spotify Connect built-in to stream millions of songs from the world’s most popular streaming service

- Native support for Qobuz with true high-res streaming up to 24-bit/192kHz quality.

- Native support for TIDAL streaming service with free 90 day trial of lossless HiFi tier

- Front-panel USB port for replay of MP3 player and USB-stored audio ( 1.6 A charge )

- vTuner 5* full-service internet radio

- Multiroom & Party Mode compatible

- iOS and Android Naim Audio app for intuitive control

- Bluetooth connectivity with aptX HD codec for quality audio playback

- Bi-directional, Zigbee®-compatible remote control

- Roon ready - turning your music collection into a beautifully laid out catalogue

Thanks to RC5 system integration, you can control compatible amplifiers that are connected to your network player directly from the Naim app on a phone or tablet.

Technology & Craft

The Burr-Brown® PCM1792A digital-to-analogue converter working alongside our new streaming platform is one of the best available. We improved its performance even further by implementing our own digital filters and adding a discrete current-tovoltage converter immediately after the DAC.

The streaming section of the NDX 2 uses the latest Naim network card featuring low noise, high-speed low-voltage differential signaling ( LVDS ) to route the digital audio signal. The higher speed is capable of decoding all HD audio formats at up to 32 bits/384 kHz or DSD128. Rather than the source acting as the digital timing master, our new streaming board turns things around and allows our DAC clock to control the flow of audio data. The data is integer-over-sampled in a SHARC DSP to an incredible 40-bit accuracy before it’s fed to the Burr-Brown DAC.

The NDX 2 features an integrated low-noise power supply with a custom-designed toroidal transformer and separate windings for the digital and analogue sections. However, the player can be upgraded with an external XPS DR or 555 PS DR power supply, giving you a marked increase in sonic authority and emotion.

During the development of the NDX 2, our engineers examined every detail, from mechanical construction, component selection and board layout. The result is a network player worthy of the Naim badge, with a sound that’s rich, detailed and engaging.

Naim Audio NDX 2 Network Music Player User's Manual

Specifications

Audio Inputs

Streaming

Chromecast built-in, Apple AirPlay, TIDAL, Spotify® Connect, Bluetooth ( AptX HD ), Internet Radio, UPnP™ ( hi-res streaming ), Roon Ready

USB

2 x USB Type A socket ( front & rear - 1.6A charge )

Digital ( S/PDIF )

2 x Optical TOSLink ( up to 24bit/96kHz )
1 x coaxial RCA ( up to 24bit/192kHz, DoP 64Fs )
1 x coaxial BNC ( up to 24bit 192kHz, DoP 64Fs )

Audio Outputs

Analogue

1 x RCA pair
1 x 5-pin DIN
Digital 1 x Coaxial BNC

Connectivity

Updates

Update your system wirelessly via the Naim app

Network

Ethernet ( 10/100Mbps )

WiFi ( 802.11 b/g/n/ac with external antenna )

Formats

Multi-room

Party Mode Streaming: Sync up to six Naim products & control via the Naim app

Internet Radio Formats

Windows Media-formatted content, MP3, ACC, OGG Vorbis streams & MMS

Internet Radio Provider

vTuner premium 5*

Audio Formats

WAV - up to 32bits/384kHz
FLAC and AIFF - up to 24bit/384Hz
ALAC ( Apple Lossless ) - up to 24bit/384Hz
MP3 - up to 48kHz, 320kbit ( 16 bit )
AAC - up to 48kHz, 320kbit ( 16 bit )
OGG and WMA - up to 48kHz ( 16 bit )
DSD - 64 and 128Fs
M4A - up to 48kHz, 320kbit ( 16 bit )
Note: Gapless playback supported on all formats.

Physical Specifications

Dimensions

( H ) 87 mm x ( W ) 432 mm x ( D ) 314 mm

Finish

Brushed & anodized aluminum

Weight

22 lbs



Power Consumption

Typical use: 19W
Network standby mode: <2W
Deep sleep: <0.5W

Ripping & Storage

Storage

2 x USB Type A socket ( front and rear - 1.6A charge )



Supplied With

Zigbee® remote includes batteries, Power-Line Lite cable ( UK denominations only ), Burndy link plug, 5-pin DIN interconnect cable, BNC to RCA adaptor, Wi-Fi ( x 2 ) and Bluetooth antennae, cleaning cloth, quick start guide



Mains Cable

Power-Line

Power Supply

555 PS DR/ XPS/ XP5 XS

Other

Super Lumina / Hi-Line

Upgrades

App Control

Naim App for iOS & Android

Front Panel

5" color LCD display & four buttons

Handheld

Zigbee® RF4CE

Shipping Weight & Dimensions: 29 lbs, 23" x 20" x 10"
