Product description
Features
- 1000 watt Total System Power ( 4 x 250 watt )
- High performance power platform
- 70V / 100V / Low Impedance Compatibility
- Flexible I/O
- State-of-the-art DSP control and set-up
Klipsch KDA-1000 Amplifier User's Manual
Specifications
| Part Number | 120V: 1063258 230V: 1063261 |
| Amplifier Type | High Efficiency Class G/H |
| Amplifier Power | 1000W Total System Power 4 x 250W Per Channel |
| Inputs | Balanced: 4 x Phoenix Line Level (up to 12 AWG wire) Unbalanced: 4 x RCA Line Level |
| Outputs | 4 x Phoenix Speaker Level (up to 12 AWG wire) 4 x RCA Line Level ( Throughs ) |
| Input Sensitivity | 750mV Balanced, 0dBU |
| Input Impedance | Balanced 40k |
| THD | <1% @ Rated Output |
| Signal-To-Noise | -100 dB Below Rated Output |
| Enclosure Type | Front Face: ABS Plastic Case: Machine Formed Steel |
| Rack Unit | 1RU |
| Product Dimensions | 1.73” x 19.02” x 14.29” ( 44 mm x 483 mm x 363 mm ) |
| Product Weight | 15 lbs ( 6.82 kg ) |
| Mount Type | Removable 1RU Rack Ears, Removable Rubber Feet |
| Built From | 2016 |
