DAC Structure

Sample rate converter: SRC4392 up-sampling data to 192kHz

Digital to Analogue converter: PCM1795 32 bit / 192kHz Multi-bit Sigma-Delta type

Performance

Output Voltage: 2 Volts RMS single-ended ( RCA )

Output Voltage: 4 Volts RMS balanced ( XLR )

PCM THD: <0.002%

PCM THD: <0.003%

DSD THD: <0.003%

DSD THD: <0.006%

PCM Frequency Response: –3dB, 2Hz to 90kHz

PCM Frequency Response: –3dB, 2Hz to 40kHz

Channel Separation: -110dB

Capabilities

Coaxial Inputs: S/PDIF up to 24 bit / 192kHz

Optical Inputs: S/PDIF up to 24 bit / 192kHz

Inputs

2 x RCA Coaxial Connector SPDIF 32-192kHz

( 16-24 bit stereo PCM )

2 x TOSLINK Optical Connector 32-192kHz

1 x USB Type ‘B’ connector

Asynchronous data stream at up to 24-bit/192kHz PCM as well as DSD64 and DSD128

( Determined by source file/computer settings )

Outputs

1 x RCA ( Single-ended )

1 x XLR Male sockets ( Balanced ) to EIA RS-297-A

General

Dimensions - ( W x H x D ) : 220 x 53 x 215 mm

Weight ( unpacked / packed ): 1.9Kg / 2.4Kg

Power Consumption: <0.25 Watts standby, <1 Watt max.

Supplied Accessories

1 x 5 Volt / 2A DC power supply ( 90-250VAC universal worldwide supply )

Windows Driver CD
